The LEDVANCE OSRAM DL Slim Square SQ210 18W 3000K WT is a square surface-mount LED downlight with a polycarbonate body and an external transformer. Its very slim housing keeps the installation depth to a minimum, making it well suited to ceilings with limited plenum space.

The built-in driver simplifies installation, and the push-wire terminal connection box requires no tools. A PMMA photo guide resists yellowing over the product lifetime. The external support frame (product code 510141) is available as an optional accessory.

Key Features

• Square LED downlight with polycarbonate body and external transformer
• Very slim housing with low installation depth
• Built-in driver for straightforward electrical connection
• Push-wire terminal connection box — no tools required
• PMMA photo guide that does not yellow over time
• 120° beam angle for broad, homogeneous light distribution
• Mounting positions: ceiling or wall

Product Benefits

• Direct replacement for luminaires with compact fluorescent lamps (CFL)
• Energy saving up to 60% compared to equivalent CFL luminaires
• Very homogeneous light output across the illuminated area
• Functional design fits general lighting, staircases, reception areas, and retail stores
• Small visible crown minimises visual intrusion on the ceiling surface

Technical Specifications

• Model: DL SLIM SQUARE SQ210 18W 3000K WT
• Power: 18W
• Colour Temperature: 3000K
• Beam Angle: 120°
• Height: 30.0 mm
• Mounting Position: Ceiling / Wall
• Protection Rating: IP20
• Impact Resistance: IK03
• Operating Temperature: -20 to +50°C
• LED Module: Non-replaceable
• Certifications: CE / CB / EAC / RoHS

Why You'll Love It

• No-tool push-wire connection makes installation fast and clean
• Up to 60% energy saving versus CFL means lower running costs in high-use spaces
• PMMA guide that resists yellowing keeps light quality consistent over years of use
• Optional external support frame (510141) available for surface-mount or retrofit installations
• Package includes 1× LEDVANCE OSRAM DL Slim Square SQ210 18W 3000K WT luminaire
