The GBC INV3P-12-2000-A is a 2000W pure sine wave power inverter that accepts 10–15 Vdc input and delivers 220–240 Vac output at 50/60 Hz. Its pure sine waveform makes it compatible with inductive loads such as refrigerators and power drills, in addition to standard household appliances.

The aluminium enclosure houses 8×30A fuses and a single cooling fan, with IP20 protection. Two Schuko output sockets and a USB port are accessible on the unit. Input is connected via crocodile clips.

Key Features

• Pure sine wave output — compatible with inductive loads (refrigerators, drills)
• 2000W nominal power with 4000W peak capacity
• Two Schuko output sockets plus a USB port
• Input via crocodile clips for direct battery connection
• On/off switch and one cooling fan built in
• Low-battery alarm at 10–10.5 Vdc; auto-shutdown at 9–9.5 Vdc undervoltage or 15.5 Vdc overvoltage

Product Benefits

• Pure sine output protects sensitive electronics and motors from waveform distortion
• 4000W peak power handles motor start-up surges without tripping
• Crocodile-clip input allows quick connection to any 12V battery without tools
• USB port charges mobile devices directly from the inverter
• Automatic over/undervoltage shutdown prevents battery damage and load damage

Technical Specifications

• Model: GBC INV3P-12-2000-A
• Input Voltage: 10–15 Vdc
• Nominal Power: 2000W
• Peak Power: 4000W
• Output Voltage: 220–240 Vac
• Output Frequency: 50/60 Hz ±0.5 Hz
• Input Current: 170 A
• Waveform: Pure sine
• Input Connection: Crocodile clips
• Output Connection: 2× Schuko
• Additional Port: USB
• Fuses: 8×30A
• Maximum Efficiency: 0.9
• Low Battery Alarm: 10–10.5 Vdc
• Undervoltage Shutdown: 9–9.5 Vdc
• Overvoltage Shutdown: 15.5 Vdc
• Minimum Battery Capacity: 200 Ah
• Protection Rating: IP20
• Material: Aluminium
• Colour: Black
• Dimensions: 42×21.5×9.1 cm
• Weight: 5.3 kg

Why You'll Love It

• Two Schuko sockets let you power two appliances simultaneously
• Compact aluminium body at 42×21.5×9.1 cm fits in vehicle storage
• On/off switch provides immediate manual control without disconnecting cables
• Package includes 1× GBC INV3P-12-2000-A inverter
