CSB HR1234W 12V 9Ah AGM UPS Battery – High-Rate Sealed Lead-Acid

The CSB HR1234W is a 12 V 9 Ah sealed lead-acid battery in valve-regulated flat-plate AGM construction — the high-rate backup cell behind countless UPS units, alarm panels and emergency-lighting systems. The 'HR' (high-rate) design is built to deliver strong current for the short, heavy discharges a UPS demands.

It meets IEC 61056-1/2 and carries a EUROBAT 3–5 year design life for standby use, with Faston 6.3 mm terminals and ~204 W (15 min) output. Maintenance-free and sealed, it mounts in any orientation.

Key Features

• 12 V 9 Ah sealed lead-acid (VRLA / AGM), high-rate design
• High current output for UPS-type short, heavy discharges
• ~204 W battery power (15 min)
• Faston 6.3 mm terminals (4-terminal layout)
• Complies with IEC 61056-1/2; EUROBAT 3–5 year design life
• Maintenance-free, sealed — mounts in any orientation

Technical Specifications

• Brand / model: CSB HR1234W
• Type: VRLA / AGM sealed lead-acid (high-rate)
• Voltage: 12 V
• Capacity: 9 Ah
• Power (15 min): ~204 W
• Terminals: Faston 6.3 mm (×4)
• Dimensions: 151 × 64.8 × 94.3 (98.6) mm
• Standards: IEC 61056-1/2
• Design life: EUROBAT 3–5 years (standby)

Product Benefits

• The exact high-rate 12 V 9 Ah cell most UPS units and alarm panels use
• HR design holds voltage under the heavy momentary load a UPS pulls
• Faston 6.3 mm terminals drop straight into standard holders
• Sealed and maintenance-free for fit-and-forget backup

Why You'll Love It

• CSB is an OEM-grade UPS battery brand — a real upgrade over no-name cells
• High-rate spec is what a UPS actually needs, not a generic 9 Ah
• Standard size and terminals make it a direct swap
