The Orno 13603 Cable Connector handles three conductors up to 6mm² each in a straight-profile body certified to IP68. It is intended for outdoor use where the junction must resist immersion, rain, and direct sunlight without an additional protective enclosure.

The PA6 polymer housing carries a UL94 V1 flame-resistance rating and is formulated to resist UV degradation. An internal tight gasket and a thick rubber cable-gland gasket together create a complete seal around all cables. Nickel-plated brass contacts maintain a clean, low-resistance connection and prevent oxidation over time.

Key Features

• IP68-rated ingress protection — resistant to immersion and harsh outdoor conditions
• Accepts 3 conductors up to 6mm² cross-section
• Dual gasket system: tight internal gasket and thick rubber cable-gland gasket
• Nickel-plated brass contacts for oxidation resistance
• UV-resistant PA6 housing rated to flame class UL94 V1
• Screw-clamp connection for reliable wire termination

Product Benefits

• IP68 certification provides full protection against water ingress at exposed outdoor junctions
• 30A current rating supports lighting circuits and other medium-load outdoor applications
• Dual sealing prevents moisture and contamination from reaching live conductors
• UV-stable housing resists embrittlement and cracking under prolonged sun exposure
• Screw-clamp terminals accommodate 10–16mm cable diameters without slipping

Technical Specifications

• Model: Orno 13603
• Connector Type: Straight
• Number of Wires: 3
• Wire Cross-Section: 6mm²
• Cable Gauge: 10–16mm
• Rated Voltage: 450V
• Rated Current: 30A
• Protection Degree (IP): IP68
• Contact Material: Nickel-plated brass
• Housing Material: PA6
• Flame Resistance: UL94 V1
• UV Resistance: Yes
• Underground Installation: No
• Diameter: 30mm
• Length: 118mm

Why You'll Love It

• Three-pole straight format covers single-phase outdoor circuits in one compact unit
• Screw-clamp design allows easy re-termination if the connected cable needs replacing
• IP68 rating ensures the junction stays protected even in rain, flooding, or hosing
• Package includes 1× Orno 13603 Cable Connector Straight IP68 3×6mm²
